- Parameters
1.Test medium: water, compressed air;
2.Test pressure:
input＜ 6.9 bar(gas);
output＜ 1100 bar(liquid);
3.Dimensions and weight:
test cabinet: L1970xW1760xH900(mm), 342kg;
electric control cabinet: L1880*W600*H600(mm), 143kg.
▍Applications
Suitable for hydrostatic test of downhole tools in oil industry. Mainly applied to hydrostatic test of cementing tool for drilling liner hanger, packer, etc.
▍Main feature
1.Equipped with high and low pressure pump, ability of quick filling of test piece. Adjustable output pressure, controllable pressurization rate.
2. Control mode: Manual control and automatic control; The two control modes can work separately and can be used alone.
3. The cabinet is the overall enclosed housing. The high pressure pipelines use the stainless steel tube. The operation button is concentrated in control panel. With 200 liters water tank, and high and low pressure pump.
4. Equipped with well-known brands components in Europe and America. With advantages of our years of design experience and high quality components, the system has features of high reliability, less maintenance and long life.
5.Installing Telide self-developed software: simple and easy operating interface, collecting of test pressure and displaying time - pressure curve diagram in real time.
▍Parameter
1.Test medium: water, compressed air;
2.Test pressure:
input＜ 6.9 bar(gas);
output＜ 1100 bar(liquid);
3.Dimensions and weight:
test cabinet: L1970xW1760xH900(mm), 342kg;
electric control cabinet: L1880*W600*H600(mm), 143kg.
