- Parameters
1.Suitable for the grinding of O ball, V ball, C ball and hemisphere(spherical φ3-200mm), and sealing surface;
2.grinding range: 3mm～200mm;
3.grinding accuracy: ≤1.0μm;
4.surface roughness: Ra≤0.1μm.
▍Applications
3D Spherical automatic grinding machine T3D-01
Used for grinding metal sealing ball valve. Simulate the way of manual grinding, improve grinding accuracy and labor efficiency compare to other grinding machine
▍Main feature
1.Ball, main seat, deputy seat, in the three-axis drive, eccentric shaft, eccentric disc, telescopic rod, preloaded spring, universal joint, simulation of manual work according to the specific trajectory , and improve the existing two-dimensional grinding;
2.Simple structure complete the task of large professional equipment, and grinding of ball and sealing surface;
3.Replace manual work , improve efficiency, uniformity of processing accuracy and reduce the technical requirements of personnel.
▍Parameter
1.Suitable for the grinding of O ball, V ball, C ball and hemisphere(spherical φ3-200mm), and sealing surface;
2.grinding range: 3mm～200mm;
3.grinding accuracy: ≤1.0μm;
4.surface roughness: Ra≤0.1μm.
